Share to LEDDR44300-1050 description Max 37.8w* constant current, non dimmable driver to suit a variety of downlights and LED fittings. Please check against the table to confirm the output current and voltage operational limits will suit your fittings. In the event it does not match but fitting is connected anyway, it may result in damage to driver and or fitting. The required current MUST be set by installer prior to connecting to LED Output 15-44vDC 300mA Max 13w 15-44vDC 350mA Max 15w 13-44vDC 400mA Max 18w 11-44vDC 450mA Max 20w 10-44vDC 500mA Max 22w 9-43vDC 550mA Max 24w 8-43vDC 600mA Max 27w 8-43vDC 650mA Max 29w 7-43vDC 700mA Max 31w 6-42vDC 750mA Max 32w 6-42vDC 800mA Max 33w 6-42vDC 850mA Max 35w 6-36vDC 900mA Max 32.4w 6-36vDC 950mA Max 34.2w 5-36vDC 1000mA Max 36w 5-36vDC 1050mA Max 37.8w Size 145 x 45 x 28 mm IP Rating 20 Dimmable No Notes Ensure good airflow to driver. Do not cover/ or abutt with insulation. Warranty 2 year replacement only warranty (does not cover costs involved with installation/re-installation) Add Inquiry Call Us Recommended Products
